Blue Sea 7547 C-Series Flat Rocker Circuit Breaker - Single Pole - 60A

(No reviews yet)

Sale $52.81 $54.44

Blue Sea Systems

SKU:

MP-65287

UPC:

632085075477

Dimension:

2.00 (cm) × 2.00 (cm) × 4.00 (cm) (W × H × D)

This item is temporarily out of stock.

Current Stock:

C-Series Flat Rocker Circuit Breaker - Single Pole - 60A

Features:

Rocker actuator is flush in the "ON" position, eliminating the risk of accidential switching
Color actuator indicates "OFF" position
Provides overcurrent protection for inverters, bow thrusters, and windlasses
Combines switching and circuit protection into a single device
"Trip Free" - cannot be held closed after trip
Ignition protectedsafe for installation aboard gasoline powered boats

Specifications:

Amperage: 60A AC / 60A DC
Actuator Style: Flat Rocker
Poles: 1
Maximum Voltage: 240V AC / 48V DC
Circuit Breaker Type: Magnetic Hydraulic - trip free
Terminal Stud Torque: 35 in-lb (3.95 Nm)
Interrupt Capacity: 3000A @ 120V AC / 3500A @ 240V AC / 5000A @ 32V DC
Minimum Operating Temperature: -40° C
Maximum Operating Temperature: 85° C
Mounting Screw: #6-32 Stainless Steel
Mounting Screw Torque: 6 in-lb (0.68 Nm)
Switching Cycles: 10000
Terminal Stud: 1/4-20 Tin-Plated Brass
Weight: 0.38lb (0.17 kg)
