Blue Sea 7615 ATD Automatic Timer Disconnect

(No reviews yet)

Sale $148.63 $153.23

Blue Sea Systems

SKU:

MP-64363

UPC:

632085076153

Dimension:

6.00 (cm) × 3.00 (cm) × 9.00 (cm) (W × H × D)

This item is temporarily out of stock.

Current Stock:

ATD Automatic Timer Disconnect

Adjustable time or voltage based battery disconnect automatically shuts off devices to preserve battery power

12V signal triggers relay to connect battery power to devices. When signal is removed the timer is activated and will disconnect devices after a preset time
Disconnect can be triggered based on time, low voltage, or removal of 12V signal
Low voltage will disconnect if time hasn_t been reached to preserve battery power
Time and voltage options can be turned off to allow 12V signal based disconnect
Clip-on cover insulates terminal connections
One-piece stainless flange nuts ensure safe and secure connections
Integrated LED indicates status

Specifications:

Nominal Voltage:12V DC
Amperage Operating Current: 175mA(Combine / 15mA(Open)
Continuous Rating:120A
Intermittent Duty: 210
Terminal Stud Size: 3/8"-16 (M10)
Time Range: 15min-4hrs
